WebEML User Manual Open and run performance monitoring
997
To assign TCA Alarm thresholds to Radio Channels/Link
1. From the resource tree area, select the Radio PM pane.
2. From the Radio PM pane, select the radio port to assign a TCA threshold.
3. In the resource tree area Configuration section, select the following settings in
the Assign PM threshold Configuration window; see Figure 748.
Figure 748 Assign PM threshold Configuration window
i. From the Monitor Point drop-down menu, select Hop Channel#0, Hop
Channel#1, or Link.
ii. From the Collection Period drop-down menu, select 15min or 24h.
iii. From the Threshold instance drop-down menu, select threshold table # [1/
6].
iv. Click Apply.
