Nokia 9500 MPR - Figure 756 Lockout Equipment Switch: Lockout Switch to Spare

WebEML User Manual Perform protection switching
1011
Figure 756 Lockout Equipment Switch: Lockout Switch to Spare
To release an EPS Switch
1. Select Protection Schemes/Slot#/Equipment Protection/Main#1 or Spare#0
in the resource tree area. See Figure 757.
2. On the Commands tab, from the New Value drop-down menu, select None.
3. Click Apply.
The Switch confirmation window displays.
4. Click OK.
Caution: Forced EPS switch equipment will cause a hit to traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
