Nokia 9500 MPR - Figure 755 Manual Equipment Switch: Spare to Main

Perform protection switching
1010
WebEML User Manual
Figure 755 Manual Equipment Switch: Spare to Main
To perform a Lockout on the EPS Spare
1. Select Protection Schemes/Slot#/Equipment Protection/Spare#0 in the
resource tree area. See Figure 756.
2. On the Commands tab, from the New Value drop-down menu, select Lockout.
3. Click Apply.
The Switch confirmation window displays.
4. Click OK.
Release 7.0.0 3DB 19286 ACAA Issue 01
