WebEML User Manual Provision port segregation/connectivity
395
Port segregation should be provisioned between radio ports and other Ethernet and/
or radio ports where connectivity is not desirable.
Figure 222 Port Segregation dialog box, P8ETH port 3.5
Note: All procedures are shown using the MSS-8 screen, however, the operation is similar
for all MSS shelves.
Caution: When parallel radio paths exist between two MSS shelves, port segregation
should be provisioned on both ends to prevent a loss of traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
