Provision cross connections
364
WebEML User Manual
Figure 199 PDH-RADIO Cross Connection
2. On the PDH_RADIO pop-up, select check box for all Flow ID numbers to be
cross connected.
3. On the PDH_RADIO pop-up, click OK.
4. On the Cross Connection screen, click Apply.
5. From the Connections tab, verify the PDH_RADIO cross-connection was
entered correctly.
To provision a PDH to Ethernet Cross Connection
Caution: When parallel radio paths exist between two MSS shelves, port
segregation should be provisioned between the parallel radio paths at both ends
to prevent a loss of traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
