Nokia 9500 MPR - Figure 247 Provision Ingress Rate Limiting by VLAN

Provision Ethernet ports
422
WebEML User Manual
To provision rate limiting by VLAN
1. Provision Rate Limiting by VLAN parameters using the following procedure.
See Figure 247 for the following procedure:
Figure 247 Provision ingress rate limiting by VLAN
a. Select Ethernet Port#n to provision (Ethernet Port #1/#8).
b. Select Policy & Translation tab.
Caution: When a VLAN Rate Limiter is activated in conjunction with a Port Rate Limiter, the
VLAN Rate Limiter applies to Ethernet frames that meet the Port Rate Limiter parameters.
Caution: If the port is involved in a mixed fiber-microwave Ring, the rate limiter may have
traffic impact.
22919
a
b
f
d
c
e
Release 7.0.0 3DB 19286 ACAA Issue 01
