Nokia 9500 MPR - Figure 115 Network Elements List Window

WebEML User Manual Administer NE list
223
1. Click New. See Figure 115.
2. In the table row just added, enter the NE IP address in the IP/DNS column.
3. Press Enter.
Figure 115 Network Elements List window
4. Click Save.
Save window opens. File already existing. Overwrite? window opens.
5. Click Yes.
File saved window opens.
6. Click OK.
To open an NE from a saved list of NEs
1. From the NEtO Overview window, click the Opens a file containing a list of
favorite NEs. icon. See Figure 116.
Note: The NE Table data is not automatically updated. If the NE details are updated (Site
Name, Site Location, Version, or IP Address) the NE Table data must be manually updated
or deleted and reloaded. The NE Table data is used for reference purposes only, the
operator must keep the data current.
Release 7.0.0 3DB 19286 ACAA Issue 01
