Configure radio parameters
860
WebEML User Manual
30. Select the Settings tab.
31. From the Protection Type drop-down menu, choose: No Protection, 1+1 HSB
(SD), or 1+1 FD protection scheme. See Figure 645.
32. From the Protection Port drop-down menu, choose Slot# Port# of protection
port.
33. Click Apply.
Figure 645 MPT ODU transceiver Protection Type provisioning
Note: Before changing the protection type provisioning, you must first apply the No
Protection option to the protection type. For example: If 1+1 HSB is provisioned and 1+1 FD
is needed, first select No Protection and click Apply, then select 1+1 FD and click Apply.
Release 7.0.0 3DB 19286 ACAA Issue 01
