WebEML User Manual Open and run performance monitoring
993
To run RSL History PM
1. From the resource tree area, select RSL History.
2. From the RSL History pane, select a radio port on which to run RSL History PM.
3. Click Stopped to start the monitoring. Figure 746 shows RSL History PM.
Figure 746 RSL History PM
Release 7.0.0 3DB 19286 ACAA Issue 01
