Configure radio parameters
788
WebEML User Manual
To open the Radio Main View
1. From the Equipment tab, select the radio in the resource tree: MSS/RADIO,
MPT-HL, MPT-HLC, or MPT ODU Dir#-Ch#. The selected radio type in the
resource list will be highlighted in blue. See Figure 595 for an example of
selecting an MPT-HC radio.
Figure 595 MPT-HC radio selected
2. Double-click on the radio type icon. See Figure 595 for an example of selecting
an MPT-HC radio.
The corresponding radio Main View displays:
− MPT Main View (MPT ODU)
− CORE Main View (MPT-HL, MPT-HLC, or MPT ODU)
− EAS Main View (MPT-HL, MPT-HLC, or MPT ODU)
− MSS CORE Main View (MPT-HL, MPT-HLC, or MPT ODU)
3. Click on the Settings tab; see Figure 596 for an example of selecting an MPT
ODU radio.
Release 7.0.0 3DB 19286 ACAA Issue 01
