Nokia 9500 MPR - Figure 761 Lockout HSB Switch: Lockout Spare Radio Channel

Perform protection switching
1016
WebEML User Manual
Figure 761 Lockout HSB Switch: Lockout Spare Radio Channel
To Release an HSB Switch
1. Select Protection Schemes/Slot#/HSB Protection/Main#1 or Spare#0 in the
resource tree area. See Figure 762.
2. On the Commands tab, from the New Value drop-down menu, select None.
3. Click Apply.
The Switch confirmation window displays.
4. Click OK.
Caution: Releasing Forced HSB switching equipment will cause a hit to traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
