Nokia 9500 MPR - Figure 579 Radio Channel Protection Scheme Parameter Tab

WebEML User Manual Provision protection scheme parameters
767
Figure 579 Radio Channel Protection Scheme Parameter tab
8. To view EPS protection scheme parameter, select Equipment Protection in the
resource tree area.
9. To view HSB protection scheme parameter, select HSB Protection in the
resource tree area.
10. To view EPS protection scheme parameter, select Rx Radio Protection in the
resource tree area.
To provision the Equipment Protection Schemes parameter
1. Select Protection Schemes/Equipment Protection in the resource tree area.
The Protection Scheme Parameters tab displays in the main window. See
Figure 580.
Release 7.0.0 3DB 19286 ACAA Issue 01
