WebEML User Manual Administer network configuration
133
Figure 43 Local Configuration (IP Address) window
2. Enter the IP address of the NE in the IP Address field.
3. Click Apply.
Communication with the radio will be lost. The user must log in to the radio using
the IP address configured in step 2.
4. Click Close.
To administer TMN Ethernet interface
1. Select MSS/Core-Main slot #1 in the resource tree area. The selected name
will highlight in blue. This selection also highlights the Main Core card in blue on
the graphical representation of the MSS-8 shelf in the resource list area.
2. Double-click on the blue CORE-Main Card. See Figure 44.
Release 7.0.0 3DB 19286 ACAA Issue 01
