Nokia 9500 MPR - Figure 636 XPIC Icon

WebEML User Manual Configure radio parameters
851
iii. Click Apply.
iv. Provision Horizontal radio channel XPIC Configuration Polarization to
Horizontal.
v. Click Apply.
9. Provision MPT ODU 1+0 Vertical XPIC Configuration:
i. Provision 1+0 Vertical radio channel. Provision the Vertical radio channel
using the following radio parameters identical to the values provisioned for
the horizontal radio channel (step 8 i).
• Mode
• Reference Channel Spacing
• Modulation
• Shifter
•TX Freq
•Rx Freq
ii. From the Option drop-down menu, choose gain configuration identical (Std/
XPIC) to the values provisioned for the horizontal radio channel (step 8 ii).
iii. Click Apply.
iv. Provision Vertical radio channel XPIC Configuration Polarization to Vertical.
v. Click Apply.
10. Open the XPIC Configuration tool. See Figure 636.
Figure 636 XPIC icon
XPIC Configuration tool displays. See Figure 637.
