Nokia 9500 MPR - Figure 663 Create Ipv6 Static Route Window

Perform IPv6 pre-provisioning
886
WebEML User Manual
Figure 663 Create IPv6 Static Route window
10. Select desired Host or Network Address Choice radio button: Host or Network.
11. Which IP Static Routing Configuration was selected?
a. If Network, go to step 12.
b. If Host, go to step 13.
12. Enter the Subnet prefix length of the radio in the Subnet prefix length text field.
13. Enter the IP Address of the radio in the IPv6 Address text field.
14. Select desired Gateway or Point to Point I/F Choice radio button: Gateway IPv6
Address or Point To Point Interface Index.
15. Which Gateway or Point to Point I/F Choice was selected?
a. If Default Gateway IP Address, go to step 16.
b. If Point To Point Interface Index, go to step 18.
Release 7.0.0 3DB 19286 ACAA Issue 01
