Nokia 9500 MPR - Figure 272 Provision SDHACC OC-3 Port

WebEML User Manual Provision equipment port
453
Figure 272 Provision SDHACC OC-3 port
6. Provision OC-3 port using the following procedure:
See Figure 272 for the following steps:
a. Select the Settings tab.
The Settings tab displays.
b. Select Port#s.n to provision: Port#s.1 or Port#s.2.
b
a
n
id
23063
e
g
j
l
h
c
f
k
m
Note: When provisioning OC-3 ports for 1+1 EPS Protection, provision the main ports. Then
only enable the spare ports. Then re-provision 1+1 EPS protection.
Note: It is not possible to enable a port while 1+1 EPS protection is enabled. To enable an
OC-3 port after 1+1 EPS protection is provisioned, the operator must disable 1+1 EPS
protection. Enable the new port. Then re-provision 1+1 EPS protection.
