WebEML User Manual Disable equipment

539

Figure 353 Enabled P32E1DS1

2. Click the Settings Tab in the resource detail area.

3. From the Equipment Type drop-down menu, select EMPTY. See Figure 354.

4. Click Apply.

Release 7.0.0 3DB 19286 ACAA Issue 01
