Provision Protection Type
778
WebEML User Manual
Figure 589 P2E3DS3 Protection Type provisioned
To provision SDH Protection Type
1. Select the card to provision with protection in the resource tree area. This
selection should also highlight the card in blue on the graphical representation
of the MSS shelf in the resource list area. See Figure 588.
2. From the Protection Type drop-down menu, select no Protection or 1+1 EPS.
Note: When provisioning ports for 1+1 EPS Protection, provision the main ports. Then only
enable the spare ports. Then re-provision 1+1 EPS protection.
Note: It is not possible to enable a port while 1+1 EPS protection is enabled. To grow an
SDH port after 1+1 EPS protection is provisioned, the operator must disable 1+1 EPS
protection. Enable the new port. Then re-provision 1+1 EPS protection.
Release 7.0.0 3DB 19286 ACAA Issue 01
