Configure radio parameters
880
WebEML User Manual
Figure 658 MPT ODU Maintenance tab
2. Select an action.
a. To mute the transmitter indefinitely, choose the On radio button.
b. To provide a duration that the transmitter will be muted, go to step 3.
3. Choose the Timed radio button. The default duration is 30 minutes.
4. Configure the Timeout parameter. The maximum duration is 2 days, 0 hours, 0
minutes.
Note: It is not possible to configure a timed Tx mute and a non-timed Tx mute at the same
time.
Release 7.0.0 3DB 19286 ACAA Issue 01
