Nokia 9500 MPR - Figure 214 PDH to Ethernet Cross Connection

WebEML User Manual Deprovision cross connections
385
2. On the PDH_RADIO pop-up, select Flow ID check box (unchecked) for all cross
connects to be deprovisioned.
3. On the PDH_RADIO pop-up, click OK.
4. On the Cross Connection screen, click Apply.
To deprovision a PDH to Ethernet cross connection
1. Double-click on the PDH port to Eth port line.
PDH-Eth pop-up displays. See Figure 214.
Figure 214 PDH to Ethernet cross connection
2. On the PDH-Eth pop-up, select Flow ID check box (unchecked) for all cross
connects to be deprovisioned.
3. On the PDH-ETH pop-up, click OK.
4. On the Cross Connection screen, click Apply.
To deprovision an SDH to Radio cross connect
1. Double-click on the SDH to RADIO line.
Release 7.0.0 3DB 19286 ACAA Issue 01
