Nokia 9500 MPR - Procedure; Figure 389 Activate Tx Mute to Node C

Upgrade a Ring to R5.1.0 software
580
WebEML User Manual
54.3 Procedure
1. Download the R5.1.0 software to all Ring Nodes.
2. Verify that no fault condition exists on the Ring.
3. Activate a Tx mute on Ring Node B toward Node C, see Figure 389. This will
cause the Ring to enter protection state.
Figure 389 Activate Tx mute to Node C
4. Activate the R5.1.0 software on Node B, see Figure 390. The activation of
R5.1.0 on Node B does not impact the Ring status, which prevents any
dependency on the time sequence of the upgrade of the East and West radio
interfaces. TDM and Ethernet traffic entering Node B is lost when the interface
toward Node A goes down due to radio interface upgrade, and is restored when
it is back up.
Release 7.0.0 3DB 19286 ACAA Issue 01
