Deprovision cross connections
386
WebEML User Manual
STM-1(OC-3)-RADIO pop-up displays. See Figure 215.
Figure 215 STM-1(OC-3)-RADIO cross connection
2. On the STM-1(OC-3)_RADIO pop-up, select Flow ID check box (unchecked) for
the cross connect to be deprovisioned.
3. On the STM-1(OC-3)_RADIO pop-up, click OK.
4. On the Cross Connection screen, click Apply.
To deprovision an SDH to LAG cross connection
1. Double-click on the SDH to RADIO LAG line.
STM-1-Radio LAG pop-up displays.
2. On the STM-1-Radio LAG pop-up, select Flow ID check box (unchecked) for the
cross connect to be deprovisioned.
3. On the STM-1-Radio LAG pop-up, click OK.
4. On the Cross Connection screen, click Apply.
To deprovision an Ethernet to Radio cross connection
1. Double-click on the ETH port to Radio port line.
