Figure 435 Node I to NE G (protected): Ethernet-radio cross-connection on NE G
a. Enter the flow ID in the Flow ID field
b. Choose the Service profile: TDM2TDM or TDM2ETH
c. Choose the TDM clock source, if the Service profile is TDM2ETH
d. Enter the DA MAC address: Node A Unicast MAC address
Note: The Destination MAC address on NE G can be either the Unicast MAC address of
Node A or that of Node D. However, the configuration on NE G affects the configuration on
other nodes in the fiber chain.
