WebEML User Manual Configure radio parameters
805
Figure 606 Provision MPT-HLC co-channel XPIC association
7. Click OK.
8. Click Apply.
9. Click Close.
10. From the MPT Main View, select the 1+0 Horizontal radio channel and verify the
correct radio channel is shown for the Associated Interface Vertical radio
channel. See Figure 607 for an example of a Provisioned Horizontal XPIC radio
channel.
