WebEML User Manual Configure radio parameters
871
i. Select the ATPC Enabled check box.
ii. Enter the Min-Max transmit power value range (dBm).
iii. Enter the Remote ATPC Rx Threshold (-min / -max dBm).
iv. Click Apply.
58. Provision the MPT ODU radio protection scheme
Select Protection Schemes tab.
Figure 654 MPT ODU transceiver Protection Criteria provisioning
Note: Revertive restoration criteria is the default value.
Note: For 1+1 FD protection type, HSB Protection is not available.
