Nokia 9500 MPR - Figure 581 HSB Protection Scheme Parameter Tab

WebEML User Manual Provision protection scheme parameters
769
Figure 581 HSB Protection Scheme Parameter tab
2. Select HSB Protection in the resource tree area.
3. From the Restoration Criteria partition, verify restoration criteria selection and
provision if required:
a. Select restoration criteria radio button, Not Revertive or Revertive.
b. Click Apply.
To provision Rx Radio Protection Schemes parameters
1. Select Protection Schemes/Rx Radio Protection in the resource tree area.
The Rx Radio Protection Scheme Parameters tab displays in the main window.
See Figure 582.
Note: For 1+1 FD protection type, HSB Protection is not available.
Release 7.0.0 3DB 19286 ACAA Issue 01
