WebEML User Manual Configure radio parameters
799
24. Provision the spare MPT-HL radio channel ATPC:
i. Select the ATPC Enabled check box.
ii. Enter the Min-Max transmit power value range (dBm).
iii. Enter the Remote ATPC Rx Threshold (-90.0 / -20.0 dBm).
iv. Click Apply.
25. Provision the MPT-HL radio protection scheme
Open the appropriate radio main view depending on your radio configuration
and select the Protection Schemes tab; see Figure 602.
Figure 602 MPT-HL transceiver protection criteria provisioning
Note: Revertive restoration criteria is the default value.
Release 7.0.0 3DB 19286 ACAA Issue 01
