Nokia 9500 MPR - Figure 340 Spare Core-E Disabled

Disable equipment
526
WebEML User Manual
Figure 340 Spare Core-E disabled
To disable a radio
1. Disable MPT-HL or MPT-HLC transceiver card on P8ETH or EASv2
Select the slot where the card is equipped in the resource tree area. The
selected name will highlight in blue. This selection also highlights the P8ETH or
EASv2 card in blue on the graphical representation of the MSS shelf in the
resource list area.
2. Click the Settings Tab in the resource detail area. See Figure 341.
Release 7.0.0 3DB 19286 ACAA Issue 01
