Nokia 9500 MPR - Figure 420 Node K to Node B: Pass-Through Cross-Connection on Node D

Provision cross connections in a mixed fiber/
microwave Ring
610
WebEML User Manual
Figure 420 Node K to Node B: pass-through cross-connection on Node D
a. Choose the flow IDs to cross-connect from the Available VLANs list
b. Choose the Service profile: TDM2TDM or TDM2ETH
c. Choose the Clock Source, if the Service profile is TDM2ETH
d. Enter the Ring Destination MAC address: Node D Multicast MAC address
e. Enter the Ring Source MAC address: Node B Unicast MAC address
To provision a cross-connection between Node K and Node B (protected)
1. One traffic end point belongs to the fiber chain. This end point (on Node B) is
protected, see Figure 421.
