Perform protection switching
1004
WebEML User Manual
• To perform a Manual Rx Radio Switch from the Spare to the Main Radio
Channel
• To perform a Lockout on the Rx Radio Spare Radio Channel
• To release an Rx Radio Switch
To open the Protection Schemes tab
1. From the Main View, select Protection Schemes Tab.
The Protection Schemes tab displays. See Figure 749.
Figure 749 Protection Schemes tab
To perform a Forced Switch on the Main Core card
1. Select Main Core card in the resource tree area. See Figure 750.
2. On the Commands tab, from the New Value drop-down menu, select Forced.
Caution: Forced switching the Core will cause a hit to traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
