Provision cross connections in a mixed fiber/
microwave Ring
730
WebEML User Manual
Figure 545 NE E to NE H: pass-through cross-connection on Node B
a. Choose the flow IDs to cross-connect from the Available VLANs list
b. Choose the Service profile: TDM2TDM or TDM2ETH
c. Choose the Clock Source, if the Service profile is TDM2ETH
d. Enter the Ring East MAC address: NE H Unicast MAC address
e. Enter the Ring West MAC address: NE E Unicast MAC address
6. Configure a pass-through cross-connection on Node C, see Figure 546.
