Nokia 9500 MPR - Figure 53 Activate Ipv6 Stack Main Menu Bar Path

WebEML User Manual Administer network configuration
143
4. From the OSPF Area Stub Flag drop-down menu, select OSPF Area Stub Flag:
True or False.
5. Click Create.
6. Click Apply.
7. Click Close.
To activate the IPv6 stack
1. Select action.
a. To provide parameters for IPv6, perform Perform IPv6 pre-provisioning. If
you activate IPv6 on the NE without performing pre-provisioning, default
parameters will be applied.
b. To activate the IPv6 stack, perform the following steps.
2. From the main menu bar, select Configuration>Network Configuration>IP
Configuration>Activate IPv6 stack. See Figure 53.
Figure 53 Activate IPv6 stack main menu bar path
A warning window opens. See Figure 54.
Note: When the 9500 MPR is used with other equipment, the OSPF interface parameters
of the equipment must be the same as those of the related TMN interface on the 9500 MPR.
Release 7.0.0 3DB 19286 ACAA Issue 01
