Nokia 9500 MPR - Figure 754 Manual Equipment Switch: Main to Spare

WebEML User Manual Perform protection switching
1009
Figure 754 Manual Equipment Switch: Main to Spare
To perform a Manual EPS Switch from Spare to Main
1. Select Protection Schemes/Slot#/Equipment Protection/Spare#0 in the
resource tree area. See Figure 755.
2. On the Commands tab, from the New Value drop-down menu, select Manual.
3. Click Apply.
The Switch confirmation window displays.
4. Click OK.
Caution: Manual EPS switching equipment will cause a hit to traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
