Enable equipment
514
WebEML User Manual
Figure 330 Enabled MPT-HC ODU on P8ETH optical Ethernet port
5.
Verify port segregation provisioning. Port segregation should be provisioned
between parallel MPT ODU radio paths at both ends when they exist on the NE.
Port segregation should be provisioned between the MPT ODU port and other
Ethernet and/or radio ports where connectivity is not desired. See Provision port
segregation/connectivity for detailed steps to view/provision port segregation.
To enable an auxiliary card
1. Select MSS-8/Slot#8 or MSS-4/Slot#4 in the resource tree area where the
Auxiliary card will be enabled. The selected slot will highlight in blue. This
selection also highlights the selected slot in blue on the graphical representation
of the MSS shelf in the resource list area. See Figure 331.
Caution: When parallel radio paths exist between two MSS shelves, port
segregation should be provisioned between the parallel radio paths at both ends
to prevent a loss of traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
