Configure radio parameters
834
WebEML User Manual
25. From the Protection Type drop-down menu, choose: No Protection, 1+1 HSB
(SD), or 1+1 FD protection scheme. Figure 597.
26. If a diversity receiver is in use, select the SD check box.
27. Click Apply.
Figure 626 MPT-HLS transceiver protection type provisioning
Note: Before changing the protection type provisioning, you must first apply the No
Protection option to the protection type. For example: If 1+1 HSB is provisioned and 1+1 FD
is needed, first select No Protection and click Apply, then select 1+1 FD and click Apply.
Note: The diversity receiver is supported on MPT-HLC version equipped with the combiner
feature. The diversity receiver is supported on the following radio configurations: 1+0 no
protection, 1+1 HSB (SD), 1+1 FD, with and without XPIC.
Release 7.0.0 3DB 19286 ACAA Issue 01
