Nokia 9500 MPR - Figure 726 Main Equipment Window: PDH E1;DS1 Transponder Card Highlighted

WebEML User Manual Line Facing PDH/SDH Tributary Loopback
967
To activate a Line Facing PDH/SDH Tributary Loopback
1. In the main equipment window, double-click the PDH/SDH Transponder Card
associated with the tributary to perform Line Facing PDH/SDH Tributary
Loopback. For E1/DS1 loopback, see Figure 726. For DS3 loopback, see
Figure 727. For SDH loopback, see Figure 728.
Figure 726 Main Equipment window: PDH E1/DS1 Transponder Card highlighted
Release 7.0.0 3DB 19286 ACAA Issue 01
