Figure 640 Provisioned MPT ODU 1+0 Horizontal XPIC radio channel
17. Select an action.
a. To Provision the MPT ODU Manual Transmit Power Level (RTPC), go to
step 48
b. To Provision the MPT ODU Automatic Transmit Power Control (ATPC), go
to step 53.
18. Provision the MPT ODU 1+1 XPIC configuration
Open the appropriate radio main view.
19. Provision MPT ODU Horizontal 1+1 HSB Configuration:
See Figure 641 for the following steps:
i. Provision 1+1 HSB protection group. See Provision the MPT ODU radio
protection type for detailed steps to provision radio channel parameters.
ii. Provision main radio channel. See step 39 or 42 for detailed steps to
provision radio channel parameters.
