Administer synchronization
344
WebEML User Manual
Figure 189 SSM Summary table
5. View SSM provisioning status.
6. Close SSM Summary Table.
To provision Radio Channel SSM support
1. Select Equipment tab.
2. Select Radio Direction to provision SSM support in the resource tree area.
For MPT-HL radio direction, select MPT-HL Dir#-Ch#. For MPT-HLC radio
direction, select MPT-HLC Dir#-Ch#. For MPT-HC/XP radio direction, select
MPT-HC Dir#-Ch#. For MPT-HC-HQAM/XP-HQAM radio direction, select
MPTHQAM Dir#-Ch#.
The selected name will be highlighted in blue. This selection also highlights the
radio icon in blue in the resource list area.
3. Double click the blue radio icon.
4. Select the Additional Settings tab in the resource detail area.
The radio direction Additional Settings tab displays. See Figure 190 for an
example.
