Nokia 9500 MPR - Figure 282 Deprovisioned P8 ETH SFP Port

WebEML User Manual Deprovision equipment ports
465
4. Click Apply.
The SFP port will display Empty. See Figure 282.
Figure 282 Deprovisioned P8ETH SFP port
5. Deprovision MSS-O SFP port
Select the MSS/CORE slot in the resource tree area. The selected name will
highlight in blue.
6. Click the Settings Tab in the resource detail area.
7. From the Port # 4 Usage drop-down menu, select port usage type Empty.
8. Click Apply.
The SFP port will display Empty.
To deprovision an E1/DS1 P32E1DS1 port
Note: Ports 5-8 will not deprovision if the port has any cross-connections associated with
the port.
Release 7.0.0 3DB 19286 ACAA Issue 01
