Open and run performance monitoring
984
WebEML User Manual
To run PM on a radio Ethernet port
1. From the resource tree area, select the Ethernet Statistics pane.
2. From the Ethernet Statistics pane, select the radio card on which to run radio
Ethernet PM.
3. Click Stopped to start the monitoring. Figure 740 shows radio QoS Ethernet port
PM.
Figure 740 Radio QoS Ethernet port PM
