Administer synchronization
340
WebEML User Manual
32. Click Apply.
Figure 187 Synchronization - Master / Revertive
To provision Synchronization — Slave
1. Select the Synchronization tab.
2. Click the Synchronization Source in the resource tree area.
3. Click the Settings Tab in the resource detail area.
Synchronization Settings tab displays. See Figure 182.
4. Select the Slave radio button in the Role partition.
5. Select a Primary Source radio button: Sync-In Port, Radio/MPT Port, or Eth
Port.
6. Which primary source was selected?
a. If Sync-In Port, go to step 7.
b. If Radio/MPT Port, go to step 10.
