WebEML User Manual Administer synchronization
341
c. If Eth Port, go to step 13.
7. In the Sync Ports partition, from the Sync In port drop-down menu, select the
Sync-In Port frequency: 1.024 MHz, 2.048 MHz, 5 MHz, or 10 MHz.
8. Select a Secondary Source radio button: Free Run Local Oscillator, E1/DS1
Port, Radio/MPT Port, Eth Port, STM-1/OC-3 port, or None.
9. Go to step 15.
10. From the Radio/MPT Port drop-down menu, select the Radio Port. The port can
be a radio channel or an L1 Radio LAG.
11. Select Secondary Source radio button: Free Run Local Oscillator, E1/DS1
Port, Sync-In Port, Radio/MPT Port, Eth Port, OC-3 port, L1 Radio LAG port,
or None.
12. Go to step 15.
13. From the Eth Port drop-down menu, select the Eth Port.
14. Select Secondary Source radio button: Free Run Local Oscillator, E1/DS1
Port, Sync-In Port, Radio/MPT Port, Eth Port, STM-1/OC-3 port, or None.
15. Which secondary source was selected?
a. If Sync-In Port, go to step 16.
b. If E1/DS1 Port, go to step 18.
c. If Radio Port, go to step 20.
d. If Eth Port, go to step 22.
e. If STM-1/OC-3 Port, go to step 24.
f. If Free Run Local Oscillator, go to step 26.
g. If None, go to step 26.
Note: If a Sync-In/Out SFP is in use, the Sync Ports area is labeled Sync In/Out
SFPs. The Sync In Port appears as NOT USED. The SFP is displayed as Sync
In Port #5, #6, #7, #8, depending on where the SFP is placed; see Figure 186.
