Administer synchronization
342
WebEML User Manual
16. In the Sync Ports partition, from the Sync In port drop-down menu, select the
Sync-In Port frequency: 1.024 MHz, 2.048 MHz, 5 MHz, or 10 MHz.
17. Go to step 26.
18. From the E1/DS1 Port drop-down menu, select the E1/DS1 Port.
19. Go to step 26.
20. From the Radio/MPT Port drop-down menu, select the Radio Port. The port can
be a radio channel or an L1 Radio LAG.
21. Go to step 26.
22. From the Eth Port drop-down menu, select the Eth Port.
23. Go to step 26.
24. From the STM1 (OC-3) Port drop-down menu, select the STM1/OC-3 Port.
25. Go to step 26.
26. Provision Sync Out Port?
a. If yes, go to step 27.
b. If no, go to step 28.
27. In the Sync Ports partition, from the Sync Out port drop-down menu, select the
Sync Out Port frequency: 1.024 MHz, 2.048 MHz, 5 MHz, or 10 MHz.
Note: If a Sync-In/Out SFP is in use, the Sync Ports area is labeled Sync In/Out
SFPs. The Sync In Port appears as NOT USED. The SFP is displayed as Sync
In Port #5, #6, #7, #8, depending on where the SFP is placed; see Figure 186.
Note: If a Sync-In/Out SFP is in use, the Sync Ports area is labeled Sync In/Out
SFPs. The Sync Out Port appears as NOT USED. The SFP is displayed as Sync
Out Port #5, #6, #7, #8, depending on where the SFP is placed; see Figure 186.
Release 7.0.0 3DB 19286 ACAA Issue 01
