Nokia 9500 MPR - Figure 49 IP Static Routing Configuration Window (Ipv6)

Administer network configuration
140
WebEML User Manual
7. Click Close.
To provision IP static routing in IPv6
1. From the main menu bar, select Configuration>Network Configuration>IP
Configuration> IP Static Routing Configuration. See Figure 47.
2. The IP Static Routing Configuration window opens. See Figure 49.
Figure 49 IP Static Routing Configuration window (IPv6)
3. Select desired Host or Network Address Choice radio button: Host or Network.
4. Which IP Static Routing Configuration was selected?
a. If Network, enter the Subnet prefix length of the radio in the Subnet prefix
length text field.
b. If Host, enter the IP Address of the radio in the IPv6 Address text field.
Release 7.0.0 3DB 19286 ACAA Issue 01
