WebEML User Manual Administer QoS configuration
149
Figure 58 QoS Configuration tool
To provision the Queue Scheduling algorithm
1. Select Scheduler Configuration tab. See Figure 58.
2. From the Mode column, select all Queues to change scheduling algorithm
(DWRR or SP). See Figure 59.
3. If Mode selection is DWRR, from the Weight column select queue weight (1 to
32). See Figure 59.
Note: The background of modified parameters is shown in yellow.
