Provision Protection Type
774
WebEML User Manual
Figure 585 MPT-HL or MPT-HLC Protection Type provisioned
To provision E1/DS1 Protection Type
1. Select the MSS/DS1 or MSS/E1 card to provision with protection in the resource
tree area. This selection should also highlight the MSS/P32E1DS1 card in blue
on the graphical representation of the MSS shelf in the resource list area. See
Figure 586.
2. From the Protection Type drop-down menu, select no Protection or 1+1 EPS.
Release 7.0.0 3DB 19286 ACAA Issue 01
