Nokia 9500 MPR - Figure 762 Release HSB Switch

WebEML User Manual Perform protection switching
1017
Figure 762 Release HSB Switch
To perform a Forced Rx Radio Switch on the Main Radio Channel
1. Select Protection Schemes/Slot#/Rx Radio Protection/Main#1 in the
resource tree area. See Figure 763.
2. On the Commands tab, from the New Value drop-down menu, select Forced.
3. Click Apply.
The Switch confirmation window displays.
4. Click OK.
Caution: Forced Rx Radio switching equipment will cause a hit to traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
