WebEML User Manual Provision cross connections
371
1. Verify port segregation provisioning. Port segregation should be provisioned
between parallel radio paths at both ends when they exist on the NE. When
making a cross connection to one of parallel radio ports, port segregation should
also be provisioned between the Ethernet port and all other parallel radio ports.
Also port segregation should be provisioned between the Ethernet and radio
ports and other Ethernet and/or radio ports where connectivity is not desirable.
See Provision port segregation/connectivity for detailed steps to view/provision
port segregation.
2. Select ETH port and drag to draw line to Radio port.
RADIO-ETH pop-up displays. See Figure 205.
Figure 205 Ethernet to Radio Cross Connection
3. On the RADIO-ETH pop-up, enter Flow ID number in the Flow ID field.
Note: Ranging is supported for RADIO-ETH cross-connection entry.
Release 7.0.0 3DB 19286 ACAA Issue 01
