Nokia 9500 MPR - Figure 220 Ethernet to Ring Cross Connection

WebEML User Manual Deprovision cross connections
391
Figure 220 Ethernet to Ring cross connection
2. On the ETH-RING pop-up, select ERP Instance to deprovision cross
connection.
3. On the ETH-RING pop-up, select Crossconnected VLANs to be deprovisioned.
4. On the ETH-RING pop-up, click <<.
5. Repeat steps 3 and 4 to deprovision additional ETH to Ring cross-connections
on this ERP Instance.
6. On the ETH-RING pop-up, click OK.
7. On the Cross Connection screen, click Apply.
To deprovision a Ring to Ring cross connection
1. Double-click on the RING to RING port line.
RING-RING pop-up displays. See Figure 221.
Release 7.0.0 3DB 19286 ACAA Issue 01
