WebEML User Manual Disable equipment
547
Figure 361 Disabled SDHACC
To disable an MPT ODU on MPTACC
1. To disable an MPT ODU on MPTACC
Select slot the MSS/MPTACC (MPT Access) card is equipped in the resource
tree area. The selected name will highlight in blue. This selection also highlights
the MPTACC (MPT Access) card in blue on the graphical representation of the
MSS-8 shelf in the resource list area.
2. Click the Settings Tab in the resource detail area. See Figure 362, which shows
an enabled MPT-HC.
Release 7.0.0 3DB 19286 ACAA Issue 01
